1 Axis SLR
SLR 300 (sans fond).png Image 1 of
SLR 300 (sans fond).png
SLR 300 (sans fond).png

SLR

from €4,700.00

For getting an academic/OEM discount or for getting a quotation, please contact us.

Longest travel range piezostage (up to 1500 microns) available in our product line. Exceptionally reliable thanks to a totally frictionless assembly.
Can be combined to form 2 or even 3 axis nanopositioning systems.

Controller included (USB optional).

Range of motion:
Controller:
Quantity:
Add To Cart

For getting an academic/OEM discount or for getting a quotation, please contact us.

Longest travel range piezostage (up to 1500 microns) available in our product line. Exceptionally reliable thanks to a totally frictionless assembly.
Can be combined to form 2 or even 3 axis nanopositioning systems.

Controller included (USB optional).

For getting an academic/OEM discount or for getting a quotation, please contact us.

Longest travel range piezostage (up to 1500 microns) available in our product line. Exceptionally reliable thanks to a totally frictionless assembly.
Can be combined to form 2 or even 3 axis nanopositioning systems.

Controller included (USB optional).

The SLR piezostage is certainly one of the best choice in terms of price/travel range ratio. Its maximum travel range starts at 100µm and ends at 1500µm.

In comparison to other systems on the market, the 800µm and 1500µm stages are exceptionally reliable due to the « FuseProtect » technology. The fuse technology is an effective way to ensure high reliability for critical applications. Thanks to the technology of damage tolerant actuator piezo stacks, the application keeps working even if a section of the actuator is damaged. The fuse technology fuses out any damaged ceramic element and the remaining ceramic elements continue to operate. Consequently, both the SLR800 and SLR1500 come with a 5 years warranty standard.


*Higher load on demand.

SLR100
SLR100
SLR200/300
SLR200/300
SLR500
SLR500
SLR800
SLR800
SLR1500
SLR1500

Related products

1 axis controller
1 axis controller

The SLR stages is used with a 1 axis controller but it can be used with a 2 or 3 axis controller for multi-axis configuration.

1 axis controller
