LFHS3

from €11,900.00

For getting an academic/OEM discount or for getting a quotation, please contact us.

Three axis ultra-high speed nanopositioner with a large 66 x 66mm aperture and resonant frequencies higher than 2kHz on both axis.
Can be combined with a coarse positionning Microstage.

Controller included (USB optional).

Range of motion:

30 µm (XY) 25 µm (Z) 30 µm (XY) 50 µm (Z) 50 µm (XY) 25 µm (Z) 50 µm (XY) 50 µm (Z) 75 µm (XY) 25 µm (Z) 75 µm (XY) 50 µm (Z)

Controller:

Analogue Analogue + USB

Quantity:

Add To Cart

For getting an academic/OEM discount or for getting a quotation, please contact us.

Three axis ultra-high speed nanopositioner with a large 66 x 66mm aperture and resonant frequencies higher than 2kHz on both axis.
Can be combined with a coarse positionning Microstage.

Controller included (USB optional).

For getting an academic/OEM discount or for getting a quotation, please contact us.

Three axis ultra-high speed nanopositioner with a large 66 x 66mm aperture and resonant frequencies higher than 2kHz on both axis.
Can be combined with a coarse positionning Microstage.

Controller included (USB optional).

The LFHS3 is a 3-axis ultra-high speed nanopositioner, offering up to 75µm travel along X and Y, up to 50 µm travel along Z, a large 66 x 66 mm aperture and resonant frequencies higher than 1.5kHz on every axis. This piezostage can be combined with a coarse positionning Microstage (See our Hybrid System).

This nanopositioner is part of our high-speed product line (High power controller available). High speed scans and step response time shorter than 2 ms are possible with the High power controller.
